| Main Performance Index |
| Air Interface Protocol |
EPC Global Class1 Gen2/ISO 18000-6C |
| RFID Frequency |
902.75MHz ~ 927.25MHz, Channel Spacing is 500kHz |
| RFID Frequency Mode |
Fixed Frequency / Frequency Hopping, 10 Frequency Hopping Points |
| Reader |
Domestic (Imported R2000 chip) |
| Reader Output Power |
1-30±1dBm |
| Conveyor Speed |
Up to 40m / min |
| Conveyor Load Bearing |
Up to 50KG |
| Efficiency |
Manual |
| Automatic Conveyor Belt |
One Conveyor / Independent Power Control |
| Material of Conveyor Belt |
Leather Belt |
| Screen Door |
Shutter Door (Electric) |
| Number of Tag Reading |
200+pcs |
| Reading Efficiency |
3~5 Seconds |
| Reading Mode |
Motionless |
| Operating Mode |
Interval T Cycle / Continuous Work / External Trigger |
| Screen |
15.6-inch Resistive Touch Screen，1920*1080 |
| Industrial Computer |
J4125/4GB+128GB |
| Photoelectric Switch |
2 Groups/Imported |
| Electronic Control |
With Domestic PLC |
| Antenna |
4 Groups of 9dbi Antennas |
| Load Capacity |
50kg |
| Adjustable Speed of Conveyor |
0—40m/min |
| Reversible or Not |
Reversible Conveyor |
| Opening Speed |
1 Second |
| Dock With Production Line or Not |
No |
| Physical Environment |
| Model Code |
SR-RUX234 |
| Tunnel size (mm) |
960 (length) × 1120 (width) × 1706 (height) |
| Ball Transfer Table Size (mm) |
1600(length) × 600 (width) × 700 (height) |
| Inner Size(mm) |
800(length) × 800(width) × 880 (height) |
| Maximum Passable Size of Box (mm) |
700(length) × 700 (width) × 700 (height) |
| Total Weight |
About 240KG |
| Operating Temperature |
-20℃– 60℃ |
| Storage Temperature |
-10℃~60℃ |
| Operating Humidity |
20-95% (non-condensing) |
| Work Voltage |
220VAC（±10%）50±3HZ |
| Power |
350W |
| Enclosure Material |
Spray-paint Carbon Steel |
| Shielding Performance |
5~10CM |
